Jackal 336 Thermal Imaging Camera Clip-On

Shepherd Scopes Jackal Series is one of the smallest infrared thermal camera Clip-on System available today.  The Jackal Series has a wide range of features that puts it at the forefront of all other clip on thermal cameras in its class.  Shepherd, in cooperation with Armasight has created a user package that is one of the only thermal camera passive range finding systems available.


The Jackal is an uncooled long-wave thermal clip-on device intended to mount in front of your existing Shepherd dual reticle range finding scope. The immediate advantages of this approach is the continued use of existing range finding bullet drop compensating reticle packages found in all of Shepherd’s advanced weapon platforms.


The Shepherd Scopes Jackal series eliminates the traditional requirement of removing your existing day scope from your rifle, to replace it with a dedicated thermal sight (which would also involve re-zeroing). The Jackal simply mounts in front of your Shepherd standard daytime sight. Factory bore-sighted to tolerances of less than 1 MOA, no re-zeroing is required.  The thermal cameras allow the user to detect targets through obstructions such as snow, dust, smoke, fog, haze, and other atmospheric obscurants.  By combining it with you Shepherd scope you get the best of both worlds.


Shepherd has included a compass and inclinometer in the Jackal Series and combines with our range finding reticle package in our day time scope platforms this combination gives accurate range and target determination in a matter of seconds. A five-button wireless remote switch is included to operate and modify the settings on the Jackal to optimize the imagery for the viewed scene without having to remove your hands from the weapon.


Utilizing the latest FLIR Quark 2 Technology, the Jackal is offered in 336×256 and 640×512 pixel formats. The wireless remote capability and Bluetooth features prevents the Jackal from becoming obsolete as new applications and software reaches maturity and comes to market. Through the multi-pin connector, the operator can record video using the Digital Video Recorder (DVR), augment the battery life by attaching to external battery options, and update/upload new software revision and applications from personal accounts associated with the Shepherd Scopes customer access web sites

ModelJackal 336
Refresh Rate60 Hz
Magnification (NTSC/PAL)Unity (1×)
Objective Lens TypeGermanium
Type of Focal Plane ArrayFLIR Quark 2
Pixel Array Format336×256
Pixel Size17 μm
Display TypeOLED SVGA 060
Pixel Display Format800x600
Display BrightnessDiscretely Adjustable to 8 Levels
Turn-on Time, max3 sec
Digital Zoom1×, 2×, 4×
Digital CompassYes
Digital InclinometerYes
Battery Status IndicatorYes
Image PalettesWhite Hot, Black Hot, Fusion, Rainbow, Sepia, Rain
Analog Input and Output Format (resolution)NTSC (640×480 pixels) / PAL (768×574 pixels)
Remote ControlWireless (5 buttons)
Active Contrast Enhancement (ACE) -“CONTRAST”Yes
Second Generation Digital Detail EnhancementYes
Smart Scene Optimization (SSO) – “SMART SCENE”Yes
Information-Based Histogram Equalization (IBHEQ) – “SKY/SEA”Yes
Linear Automatic Gain Control (Linear AGC)Yes
User-Controlled Manual Non-Uniformity Correction/ Flat-Field Correction (UCMNUC/ FFC)Yes
Silent Shutterless NUC ™ (SSN)Yes
Objective Focal Length19 mm
Objective F-numberF/1.25
Field of View (ang.)17.2° x 13.2°
Exit Pupil Diameter27 mm
BatteryOne CR123A 3V Lithium battery, CR123 rechargeable battery, or 16650 rechargeable battery
with voltage from 3.0V to 3.6V
Battery Life at 20 °C (68 °F)CR123A - up to 1.5 hr
CR123 Rechargeable (650mAh) - up to 1 hr
16650 Rechargeable (2000mAh) - up to 2.6 hr
Extended Battery PackTwo 18650 rechargeable batteries (3.7V), four CR123 rechargeable batteries with voltage 3.7V max,
or four standard CR123A 3V Lithium batteries (operational time up to 8 hr)
External Power Supply6V-12V DC / 600 mА
Operating Temperature-40 to +50°C (-40 to +122°F)
Storage Temperature-50 to +70°C (-58 to +158°F)
Recoil Resistance700  g
Environmental RatingWater and fog-resistant
Overall Dimensions124×63×49 mm (4.9×2.4×2.0 in)
Weight (w/o Batteries)250 g (0.54 lbs)
Height of the Scope Axis above Rail37 mm (1.5 in)
Warranty3 years
Warranty on FLIR detector10 years
